Lavalink Client

An easy, flexible, and feature-rich Lavalink v4 Client for both beginners and experts.

🚀 Features

  • 💯 Lavalink v4 Native: Full support for Lavalink v4, including its powerful plugin ecosystem.
  • ✅ Detailed Player-Destroy Reasons: Understand precisely why a player was destroyed (e.g., channel deleted, bot disconnected).
  • ✨ Flexible Queue Stores: Use the default in-memory store or bring your own (Redis, databases, etc.) to sync queues across multiple processes.
  • 🎶 Unresolved Tracks: Supports unresolved track objects, fetching full data only when a track is about to play, saving API requests and resources.
  • 🎚️ Built-in Filters & EQ: Easy-to-use management for audio filters and equalizers.
  • 🔍 Advanced Queue Filtering: Search and filter tracks in the queue by title, author, duration, and more with powerful query options.
  • ⚙️ Advanced Player Options: Fine-tune player behavior for disconnects, empty queues, volume handling, and more.
  • 🛡️ Lavalink-Side Validation: Ensures you only use filters, plugins, and sources that your Lavalink node actually supports.
  • 🔒 Client-Side Validation: Whitelist and blacklist URLs or domains to prevent unwanted requests and protect your bot.
  • 🧑‍💻 Developer-Friendly: A memory-efficient design with a clean, intuitive API that mirrors Lavalink’s own implementation.
  • 🤖 Automated Handling: Automatically handles track skipping on errors, voice channel deletions, server-wide mutes, and much more.

📦 Installation

Latest Stable Version: v2.9.x

👉 via NPM
Terminal window
# Stable (install release)
npm install --save lavalink-client


# Development (Install github dev-branch)
npm install --save tomato6966/lavalink-client
👉 via YARN
Terminal window
# Stable (install release)
yarn add lavalink-client


# Development (Install github dev-branch)
yarn add tomato6966/lavalink-client
👉 via BUN
Terminal window
# Stable (install release)
bun add lavalink-client


# Development (Install github dev-branch)
bun add tomato6966/lavalink-client
👉 via pnpm
Terminal window
# Stable (install release)
pnpm add lavalink-client


# Development (Install github dev-branch)
pnpm add tomato6966/lavalink-client

📖 Documentation & Guides

Node Link

This client can be used with nodelink too, but because nodelink’s websocket is different than the one from lavalink, you need to disable a few things on the NODE OPTIONS / NODE PROPERTIES:

nodeOptions.nodeType = "NodeLink";

this can be done directly when creating the node in the lavalinkmanager.

client.lavalink = new LavalinkManager({
    nodes: [
        {
            host: "localhost",
            nodeType: "NodeLink",
        },
    ],
});
// or here if you need a bigger example.
client.lavalink = new LavalinkManager({
    nodes: [
        {
            authorization: "youshallnotpass", // The password for your Lavalink server
            host: "localhost",
            port: 2333,
            id: "Main Node",
            // set to nodeLink
            nodeType: "NodeLink",
        },
    ],
    // A function to send voice server updates to the Lavalink client
    sendToShard: (guildId, payload) => {
        const guild = client.guilds.cache.get(guildId);
        if (guild) guild.shard.send(payload);
    },
    autoSkip: true,
    client: {
        id: process.env.CLIENT_ID, // Your bot's user ID
        username: "MyBot",
    },
});

Now if you want to use NodeLink specific functions, you can use the type assertion checker function:

if (node.isNodeLink()) {
    // node is now typed as NodeLink
    node.addMixerLayer();
} else if (node.isLavalinkNode()) {
    // node is now typed as LavalinkNode
} else {
    // node is now typed as whatever it is..
}

or you have to assert the type…

const node = client.lavalink.lavalinkManager.getNode("id") as NodeLinkNode;
node.addMixerLayer()
  • node.getYoutubeOAUTH(refreshToken): Exchange a Refresh Token for an Access Token. Docs
  • node.updateYoutubeOAUTH(refreshToken): Update the OAUTH token. Docs
  • node.getChapters(player, track?): Retrieve Chapters of Youtube Videos. Docs
  • node.nodeLinkLyrics(player, track?, language?): Retrieve Lyrics of Youtube Videos. Docs
  • node.getDirectStream(track): Stream audio directly from NodeLink. Docs
  • node.listMixerLayers(player): Retrieves a list of currently active mix layers. Docs
  • node.addMixerLayer(player, track, volume): Adds a new audio track to be mixed. Docs
  • node.removeMixerLayer(player, mixId): Removes a specific mix layer. Docs
  • node.updateMixerLayerVolume(player, mixId, volume): Updates the volume of a specific mix layer. Docs
  • node.changeAudioTrackLanguage(player, language_audioTrackId): Changes the current language of the audio. Docs
  • node.updateYoutubeConfig(refreshToken?, visitorData?): Updates the YouTube configuration. Docs
  • node.getYoutubeConfig(validate?): Gets the YouTube configuration.
  • node.getConnectionMetrics(): Get connection metrics. Docs
  • node.loadDirectStream(track, volume, position, filters): Stream raw PCM audio. Docs
// NodeLink specific events
client.lavalink.nodeManager.on("nodeLinkEvent", (node, eventName, player, track, payload) => {
    switch (eventName) {
        // -------------Player LifeCycle Events-------------
        // https://nodelink.js.org/docs/api/websocket#playercreatedevent
        case "PlayerCreatedEvent":
            {
                // { "guildId": "987654321098765432", "track": null, "paused": false, "volume": 100 }
                const playerInfo = payload.player;
                console.log(`Player created in guildId: ${playerInfo.guildId}`);
            }
            break;
        // https://nodelink.js.org/docs/api/websocket#playerdestroyedevent
        case "PlayerDestroyedEvent":
            {
                // "987654321098765432"
                const playerInfo = payload.guildId;
                console.log(`Player destroyed in guildId: ${playerInfo.guildId}`);
            }
            break;
        // https://nodelink.js.org/docs/api/websocket#playerconnectedevent
        case "PlayerConnectedEvent":
            {
                // { "sessionId": "abc", "token": "token", "endpoint": "us-central123.discord.media", "channelId": "123456789012345678" }
                const playerInfo = payload.voice;
                console.log(`Player connected in guildId: ${playerInfo.guildId}`);
            }
            break;
        // https://nodelink.js.org/docs/api/websocket#playerreconnectingevent
        case "PlayerReconnectingEvent":
            {
                // { "sessionId": "abc", "token": "token", "endpoint": "us-central123.discord.media", "channelId": "123456789012345678" }
                const playerInfo = payload.voice;
                console.log(`Player reconnecting in guildId: ${playerInfo.guildId}`);
            }
            break;


        // -------------Player State Events-------------
        // https://nodelink.js.org/docs/api/websocket#volumechangedevent
        case "VolumeChangedEvent":
            {
                // "guildId": "987654321098765432",
                // "volume": 100
                const { guildId, volume } = payload;
                console.log(`Player volume changed in guildId: ${guildId} to ${volume}`);
            }
            break;
        // https://nodelink.js.org/docs/api/websocket#filterschangedevent
        case "FiltersChangedEvent":
            {
                // { ...Filtersdata... }
                const { guildId, filters } = payload;
                console.log(`Player filters changed in guildId: ${guildId}, new Data: `, filters);
            }
            break;
        // https://nodelink.js.org/docs/api/websocket#seekevent
        case "SeekEvent":
            {
                // "guildId": "987654321098765432",
                // "position": 10000,
                const { guildId, position } = payload;
                console.log(`Player seeked in guildId: ${guildId}, new position: ${position}`);
            }
            break;
        // https://nodelink.js.org/docs/api/websocket#pauseevent
        case "PauseEvent":
            {
                // "guildId": "987654321098765432",
                // "paused": true
                const { guildId, paused } = payload;
                console.log(`Player paused in guildId: ${guildId}, paused true/false: ${paused}`);
            }
            break;
        // https://nodelink.js.org/docs/api/websocket#connectionstatusevent
        case "ConnectionStatusEvent":
            {
                // "guildId": "987654321098765432",
                // "status": "CONNECTED"
                // "metrics": { ... }
                const { guildId, status, metrics } = payload;
                console.log(
                    `Player connection status changed in guildId: ${guildId}, status: ${status}, metrics: `,
                    metrics,
                );
            }
            break;


        // -------------LYRICS EVENTS-------------
        // https://nodelink.js.org/docs/api/websocket#lyrics-events
        case "LyricsFoundEvent":
            {
                // "guildId": "987654321098765432",
                // "lyrics": "..."
                const { guildId, lyrics } = payload;
                console.log(`Lyrics found in guildId: ${guildId}, lyrics: `, lyrics);
            }
            break;
        // https://nodelink.js.org/docs/api/websocket#lyricslineevent
        case "LyricsLineEvent":
            {
                // "guildId": "987654321098765432",
                // "lineIndex": 0,
                // "line": "..."
                const { guildId, lineIndex, line } = payload;
                console.log(`Lyrics line in guildId: ${guildId}, lineIndex: ${lineIndex}, line: `, line);
            }
            break;
        // https://nodelink.js.org/docs/api/websocket#lyricsnotfoundevent
        case "LyricsNotFoundEvent":
            {
                // "guildId": "987654321098765432",
                const { guildId } = payload;
                console.log(`Lyrics not found in guildId: ${guildId}`);
            }
            break;


        // -------------AUDIO MIXER EVENTS-------------
        // https://nodelink.js.org/docs/api/websocket#mixstartedevent
        case "MixStartedEvent":
            {
                // "guildId": "987654321098765432",
                // "mixId": "123456789012345678"
                // "volume": 0.8,
                // "track": { ...TrackData... }
                const { guildId, mixId, volume, track } = payload.player;
                console.log(
                    `Player mix started in guildId: ${guildId}, mixId: ${mixId}, volume: ${volume}, track: `,
                    track,
                );
            }
            break;
        // https://nodelink.js.org/docs/api/websocket#mixendedevent
        case "MixEndedEvent":
            {
                //  "guildId": "987654321098765432",
                //  "mixId": "123456789012345678",
                //  "reason": "USER_STOPPED"
                const { guildId, mixId, reason } = payload;
                console.log(`Player mix ended in guildId: ${guildId}, mixId: ${mixId}, reason: ${reason}`);
            }
            break;
    }
});

💖 Used In

This client powers various Discord bots:

🛠️ Configuration Examples

Basic Setup

A minimal example to get you started quickly.

import { LavalinkManager } from "lavalink-client";
import { Client, GatewayIntentBits } from "discord.js"; // example for a discord bot


// Extend the Client type to include the lavalink manager
declare module "discord.js" {
    interface Client {
        lavalink: LavalinkManager;
    }
}


const client = new Client({
    intents: [GatewayIntentBits.Guilds, GatewayIntentBits.GuildVoiceStates],
});


client.lavalink = new LavalinkManager({
    nodes: [
        {
            authorization: "youshallnotpass", // The password for your Lavalink server
            host: "localhost",
            port: 2333,
            id: "Main Node",
        },
    ],
    // A function to send voice server updates to the Lavalink client
    sendToShard: (guildId, payload) => {
        const guild = client.guilds.cache.get(guildId);
        if (guild) guild.shard.send(payload);
    },
    autoSkip: true,
    client: {
        id: process.env.CLIENT_ID, // Your bot's user ID
        username: "MyBot",
    },
});


// Listen for the 'raw' event from discord.js and forward it
client.on("raw", (d) => client.lavalink.sendRawData(d));


client.on("ready", () => {
    console.log(`Logged in as ${client.user.tag}!`);
    // Initialize the Lavalink client
    client.lavalink.init({ ...client.user });
});


client.login(process.env.DISCORD_TOKEN);
🔩 Complete Configuration Example (almost all Options)
import { LavalinkManager, QueueChangesWatcher, QueueStoreManager, StoredQueue } from "lavalink-client";
import { RedisClientType, createClient } from "redis";
import { Client, GatewayIntentBits, User } from "discord.js";


// It's recommended to extend the Client type
declare module "discord.js" {
    interface Client {
        lavalink: LavalinkManager;
        redis: RedisClientType;
    }
}


const client = new Client({
    intents: [GatewayIntentBits.Guilds, GatewayIntentBits.GuildVoiceStates],
});


client.lavalink = new LavalinkManager({
    nodes: [
        {
            authorization: "youshallnotpass",
            host: "localhost",
            port: 2333,
            id: "testnode",
            secure: false, // Set to true for wss://
            retryAmount: 5,
            retryDelay: 10_000, // 10 seconds
        },
    ],
    sendToShard: (guildId, payload) => client.guilds.cache.get(guildId)?.shard?.send(payload),
    autoSkip: true, // automatically play the next song of the queue, on: trackend, trackerror, trackexception
    client: {
        id: process.env.CLIENT_ID,
        username: "TESTBOT",
    },
    playerOptions: {
        applyVolumeAsFilter: false,
        clientBasedPositionUpdateInterval: 50,
        defaultSearchPlatform: "ytmsearch",
        volumeDecrementer: 0.75,
        onDisconnect: {
            autoReconnect: true,
            destroyPlayer: false,
        },
        onEmptyQueue: {
            destroyAfterMs: 30_000,
            // function get's called onqueueempty, and if there are songs added to the queue, it continues playing. if not then not (autoplay functionality)
            // autoPlayFunction: async (player) => { /* ... */ },
        },
        useUnresolvedData: true,
    },
    queueOptions: {
        maxPreviousTracks: 10,
        queueStore: new MyCustomRedisStore(client.redis),
        queueChangesWatcher: new MyCustomQueueWatcher(client),
    },
    // Whitelist/Blacklist links or words
    linksAllowed: true,
    linksBlacklist: ["somebadsite.com"],
    linksWhitelist: [],
    advancedOptions: {
        debugOptions: {
            noAudio: false,
            playerDestroy: { dontThrowError: false, debugLog: false },
        },
    },
});


client.on("raw", (d) => client.lavalink.sendRawData(d));
client.on("ready", () => client.lavalink.init({ ...client.user }));


// Example Custom Redis Queue Store
class MyCustomRedisStore implements QueueStoreManager {
    private redis: RedisClientType;
    constructor(redisClient: RedisClientType) {
        this.redis = redisClient;
    }
    private key(guildId: string) {
        return `lavalinkqueue_${guildId}`;
    }
    async get(guildId: string) {
        return await this.redis.get(this.key(guildId));
    }
    async set(guildId: string, data: string) {
        return await this.redis.set(this.key(guildId), data);
    }
    async delete(guildId: string) {
        return await this.redis.del(this.key(guildId));
    }
    async parse(data: string): Promise<Partial<StoredQueue>> {
        return JSON.parse(data);
    }
    stringify(data: Partial<StoredQueue>): string {
        return JSON.stringify(data);
    }
}


// Example Custom Queue Watcher
class MyCustomQueueWatcher implements QueueChangesWatcher {
    private client: Client;
    constructor(client: Client) {
        this.client = client;
    }
    shuffled(guildId: string) {
        console.log(`Queue shuffled in guild: ${guildId}`);
    }
    tracksAdd(guildId: string, tracks: any[], position: number) {
        console.log(`${tracks.length} tracks added at position ${position} in guild: ${guildId}`);
    }
    tracksRemoved(guildId: string, tracks: any[], position: number) {
        console.log(`${tracks.length} tracks removed at position ${position} in guild: ${guildId}`);
    }
}

📢 Events

Listen to events to create interactive and responsive logic.

These events are emitted from the main LavalinkManager instance and relate to players and tracks.

  • playerCreate (player)
  • playerDestroy (player, reason)
  • playerDisconnect (player, voiceChannelId)
  • playerMove (player, oldChannelId, newChannelId)
  • trackStart (player, track)
  • trackEnd (player, track)
  • trackStuck (player, track, payload)
  • trackError (player, track, payload)
  • queueEnd (player)
📢 Example for Manager-Event-Listeners
// Example: Listening to a track start event
client.lavalink.on("trackStart", (player, track) => {
    const channel = client.channels.cache.get(player.textChannelId);
    if (channel) channel.send(`Now playing: ${track.info.title}`);
});


// Example: Handling queue end
client.lavalink.on("queueEnd", (player) => {
    const channel = client.channels.cache.get(player.textChannelId);
    if (channel) channel.send("The queue has finished. Add more songs!");
    player.destroy();
});

Node Manager Events

These events are emitted from lavalink.nodeManager and relate to the Lavalink node connections.

  • create (node)
  • connect (node)
  • disconnect (node, reason)
  • reconnecting (node)
  • destroy (node)
  • error (node, error, payload)
  • resumed (node, payload, players)
📢 Example for Node-Event-Listeners
// Example: Logging node connections and errors
client.lavalink.nodeManager.on("connect", (node) => {
    console.log(`Node "${node.id}" connected!`);
});


client.lavalink.nodeManager.on("error", (node, error) => {
    console.error(`Node "${node.id}" encountered an error:`, error.message);
});

📚 Advanced How-To Guides

How to Implement Session Resuming

Resuming allows your music bot to continue playback even after a restart.

  1. Enable Resuming on the Node: When a node connects, enable resuming with a timeout.
  2. Listen for the resumed Event: This event fires on a successful reconnect, providing all player data from Lavalink.
  3. Re-create Players: Use the data from the resumed event and your own saved data (from a database/store) to rebuild the players and their queues.

💡 For a complete, working example, see the official test bot’s implementation.

💡 Principle of how to enable **resuming**
// 1. Enable resuming on connect
client.lavalink.nodeManager.on("connect", (node) => {
    // Enable resuming for 5 minutes (300,000 ms)
    node.updateSession(true, 300_000);
});


// 2. Listen for the resumed event
client.lavalink.nodeManager.on("resumed", async (node, payload, fetchedPlayers) => {
    console.log(`Node "${node.id}" successfully resumed with ${fetchedPlayers.length} players.`);


    for (const lavalinkData of fetchedPlayers) {
        // 3. Get your saved data (e.g., from Redis/DB)
        const savedData = await getFromDatabase(lavalinkData.guildId);
        if (!savedData || !lavalinkData.state.connected) {
            if (savedData) await deleteFromDatabase(lavalinkData.guildId);
            continue; // Skip if no saved data or Lavalink reports disconnected
        }


        // Re-create the player instance
        const player = client.lavalink.createPlayer({
            guildId: lavalinkData.guildId,
            voiceChannelId: savedData.voiceChannelId,
            textChannelId: savedData.textChannelId,
            // Important: Use the same node that was resumed
            node: node.id,
            // Set volume from Lavalink's data, accounting for the volume decrementer
            volume: lavalinkData.volume,
            selfDeaf: savedData.selfDeaf,
        });


        // Re-establish voice connection
        await player.connect();


        // Restore player state
        player.paused = lavalinkData.paused;
        player.lastPosition = lavalinkData.state.position;
        player.filterManager.data = lavalinkData.filters;


        // Restore the queue
        await player.queue.utils.sync(true, false); // Syncs with your QueueStore


        // Restore the current track
        if (lavalinkData.track) {
            player.queue.current = client.lavalink.utils.buildTrack(lavalinkData.track, savedData.requester);
        }
    }
});


// Persist player data on updates to use for resuming later
client.lavalink.on("playerUpdate", (oldPlayer, newPlayer) => {
    saveToDatabase(newPlayer.toJSON());
});


// Clean up data when a player is permanently destroyed
client.lavalink.on("playerDestroy", (player) => {
    deleteFromDatabase(player.guildId);
});

How to Use Plugins

Lavalink client supports most of the major lavalink-plugins. The client itself is - for beginner friendly reasons - atm not extendable (via plugins) You can just use the built in functions (sponsor block, lyrics) or search plattforms (deezer, spotify, apple music, youtube, …) and use the lavalink-plugins without any configuration on the client side.

Some plugins require extra-parameters, such as flowerytts: Pass extra parameters to the search function to use plugin-specific features.

How to use the flowerytts plugin
// Example for flowertts plugin
const query = interaction.options.getString("text");
const voice = interaction.options.getString("voice"); // e.g., "MALE_1"


const extraParams = new URLSearchParams();
if (voice) extraParams.append(`voice`, voice);


// All params for flowertts can be found here: https://flowery.pw/docs
const response = await player.search(
    {
        query: `${query}`,
        // This is used by plugins like ftts to adjust the request
        extraQueryUrlParams: extraParams,
        source: "ftts", // Specify the plugin source
    },
    interaction.user, // The requester
);


// Add the TTS track to the queue
if (response.tracks.length > 0) {
    player.queue.add(response.tracks[0]);
    if (!player.playing) player.play();
}
